Joyal fine crusher

(Rating: 3.60 / 5 - total 10 votes)
Loading...
Date: 2011-11-11


The Super-Fineness Energy-Saving Crusher has been developed and improved by combining the advantages of the technology from Germany and China, so that the structure design has been further optimized.

This series feature of rational multi crushing chambers and novel double adjusting mechanism, which can ensure 85% of the discharged materials less than 3mm, and the uniformity of the product fineness can be controlled.

Easy access for maintenance has made the hammers and screen bars replaced more easily. All the wearing parts are made of new type of high chromium alloy materials with multiple elements so as to ensure the abrasive property and impact-resisting property of hammers and liner plates.

This series of fine impact crushers also feature of stable operation, low dust and less power consumption which have prestigious advantages when comparing with conventional crushers.

This series of fine crushers have been widely used for crushing mid-hard materials such as limestone, cement clinker, iron ore, shale, dolomite, gypsum, pyrites and mineral slag in chemical, construction, mining, coal processing, sand making and refractory industries.

Fine Crusher Features:
(1). Super-fineness crushing capability: The new particle size adjusting mechanism guarantees 85% of the particles controlled within 3mm;
(2). High-efficient and energy-saving: 40% power consumption reduced at equivalent output;
(3). Extra long life: hammer heads are made of new type of high quality alloy materials with multiple elements and can be turned for use thus to prolong the service life by 4 times.
(4). Great crushing ratio: Crushing for limestone into one step.
(5). Easy Maintenance: The rear cover of the upper machine frame can be hydraulically (hand)-opened to make the maintenance much easier.

Ring Hammer Crusher
This series of machine broke materials through the high-speed rotating hammer body and collision the material surfaceit has a simple structure, large crushing ratio, high production efficiency and other characteristicsit can be used for dry and wet two forms crushingit applies to mining, cement, coal, metallurgy, building materials, roads, fire and other departments chronology medium hardness and brittle materials. The device can change material particle size and adjust gap of article grate in accordance with user requirements, so it can meet different users demand.

Characteristics of Ring Hammer Crusher
This ring hammer crusher has simple structureConvenient operation and maintenancebest-selling both in domestic and abroadwell received by users.

Main Purpose of Ring hammer crusher
Ring hammer crusher for crushing all kinds of hard and abrasive weak materials. The material compressive strength does not exceed of 100Mpa, Moisture content is less than 15%. Broken material is coal, salt, chalk, gypsum, brick, limestone etc. it also can broke fiber structuremore flexibility and toughness of the broken woodpaperwaste of asbestos cementrecycling of asbestos fibers and so on. Besides, Hammer crusher can be used not only in broken production linesand production line systembut also can replace the cone crusher in the mineral processing production line.

The main working parts of ring hammer crusher is the rotor with a hammer (or hammer)rotor is composed of spindle, disk, pin and hammer. The motor drive the rotor with high-speed rotation in the broken cavitymaterials from the up mouth feeder into the machineit is crushed by high-speed movement of the hammer blows impact, shear, grinding. Under the rotor, there is a screening plate, the crushed material whose size is smaller than the sieve can come out through the sieve, and the other material whose size is bigger than the sieve will still be combated and grinded by the hammer, finally through the plate out.
