Ball Mill Classifier

This machine is a high performance classifier which is improved on the basis of foreign wind swept coal milldynamic separator. It is a new generation one that is combined coarse powder separating with eddy currents classifying.
It is a specialized in classifier equipment for ball mill, has the advantages of lower investment, high reliability, better classification, steady running condition, fineness of adjustment in convenient and less resistance etc.


Main Specifications:

Model	D350	D500	D700	D1000	D1500
Capacity of Coal Powder（t/h）	10-14	15-21	21-30	30-42	45-63
Air Content （Nm/min）	350	500	700	1000	1500
Speed（rpm）	230-348	221-329	186-289	186-276	160-238
Max Speed（rpm）	384	371	312	320	300
Resistance （kPe）	1.6-2.2
Motor Power（kw）	YCTL225-45 (15kw)	22	30	45	55
Gearbox Type	Belt Pulley	ZF108-k2-180	ZF128-l2-200	Zf148-k2-225	B2SV04B
Gearbox Ratio	3.25	3.98	4.73	4.44	5
Model of Dry Petrol Stations	SGZ-8
Weight（kg）	4630	5213	5464	6125	10408
